| Housing dimensions (H x W x D) |
96 x 22.5 x 110.5 mm |
| Housing type |
DIN rail housing (for DIN rail version EN 50022) |
| Housing material |
Polycarbonate |
| Weight |
approx. 115 g |
| IP Code |
IP20 |
| Power supply |
power supply via ConBridge |
| Operating temperature |
0 °C….+60 °C |
| Storage temperature |
-40 °C….+70 °C |
| Humidity (at 40°C) |
93% (non-condensing) |
| Connectors |
4-pole screw terminal |
| Optical indicator |
1 status LED (green) |
| CAN Controller |
Holt HI-3110 |
| Baud rate |
Up to 1 Mbit/sec. |
| CAN Version |
CAN 2.0B |
| Software interface |
Accessible via SocketCAN of the Linux operating system |
| Terminating resistor |
Switchable integrated terminating resistor |
| Connection compatibility |
Exclusively connectable via ConBridge of RevPi Connect |
| CE conformity |
Yes |
| RoHS conformity |
Yes |
| ESD test |
Passed (according to EN 61000-4-2) |
